MRCOOL® 9k DIY 5th Generation Mini-split Air Handler 115v

MRCOOL DIY 5th Gen 9K BTU Mini Split — Complete System 115V (Outdoor+Indoor+25ft Lineset)
Model DIY-09-HP-WMAH-115D25-O

The MRCOOL Easy Pro 5th Generation 9,000 BTU Mini Split System is an efficient and affordable heating and cooling solution designed for rooms up to 400 square feet. This complete system includes an outdoor condenser, indoor air handler, and a pre-charged 16-foot line set, making installation faster and more convenient.

Perfect for bedrooms, home offices, garages, workshops, and small living spaces, the Easy Pro Series combines reliable year-round comfort, quiet operation, and smart technology in a compact and energy-efficient package.

Key Features

• Complete heating and cooling system for spaces up to 400 sq. ft.
• Includes a 16 ft. pre-charged line set for simplified installation
• SmartHVAC® Wi-Fi technology for remote control from your smartphone
• Compatible with Amazon Alexa® and Google Assistant®
• High-efficiency inverter technology helps reduce energy consumption
• Ultra-quiet indoor operation
• Gold Fin® corrosion-resistant coating for enhanced durability
• Low ambient cooling operation for specialized applications
• Multiple operating modes including Sleep, Auto, Timer, and Follow Me®

Specifications

Cooling Capacity: 9,000 BTU

Heating Capacity: 10,000 BTU

Coverage Area: Up to 400 sq. ft.

SEER2 Rating: 20.2

HSPF2-4 Rating: 9.2

Voltage: 115V

Phase: Single Phase

Frequency: 60 Hz

Refrigerant: R-454B

Compressor Type: Rotary

Indoor Sound Level: 18 – 43 dBA

Outdoor Sound Level: 54 dBA

Included Line Set: 16 ft.

Maximum Line Length: 82 ft.

Liquid Line Size: 1/4 in.

Suction Line Size: 1/2 in.

Maximum Fuse Breaker: 20 A

Minimum Circuit Ampacity: 17 A

Indoor Unit Dimensions

Width: 28.70 in.

Depth: 7.87 in.

Height: 11.50 in.

Weight: 17.64 lbs

Outdoor Unit Dimensions

Width: 28.35 in.

Depth: 10.63 in.

Height: 19.49 in.

Weight: 54.45 lbs

Warranty

Parts Warranty: 2 Years

Compressor Warranty: 1 Year

The MRCOOL Easy Pro 9K Mini Split delivers efficient performance, convenient smart controls, and dependable comfort throughout every season. It is an excellent solution for homeowners looking for an easy-to-own, energy-efficient heating and cooling system.
